Internal in |
Wall width |
External |
W.P. |
Number of inserts |
Bending radius |
Weight |
Coil length |
|
|
mm |
inches |
in mm |
in mm |
(max.)bar |
(min.) in mm |
(min.) in mm |
(max.)m |
|
|
5 |
3/16 |
3.5 |
12 |
10 |
2 |
40 |
0.1 |
100 |
|
6 |
1/4 |
3 |
12 |
10 |
2 |
45 |
0.15 |
10 |
|
8 |
5/16 |
3 |
14 |
10 |
2 |
55 |
0.12 |
100 |
|
10 |
3/8 |
3.5 |
17 |
10 |
2 |
60 |
0.17 |
50 |
|
13 |
1/2 |
3.5 |
20 |
10 |
2 |
80 |
0.24 |
50 |
|
16 |
5/8 |
4 |
24 |
10 |
2 |
100 |
0.33 |
50 |
|
19 |
3/4 |
4.5 |
28 |
10 |
2 |
120 |
0.43 |
50 |
|
22 |
|
4.5 |
31 |
10 |
2 |
132 |
0.5 |
50 |
|
25 |
1 |
5 |
35 |
10 |
2 |
150 |
0.62 |
50 |
