Korean technology. Double layers Special formula compounding with high tight knitting polyester structure.(W.P.60BAR,B-P-220BAR) Light weight and easy handle than normal rubber steel reinforced hose. High tenacity,elasticity and light weight. Excellent resilience. Excellent abrasion resistant, aging resistant.
High pressure industrial applications
Pesticide & water spray equipment in agriculture
Compressed air in garages and service stations
Factory air line
Automation machinery and pneumatic tools
Construction works
Air plumbing
Good flexible and durability against climate.
TEMPERATURE -5°C-+65°C
PART # | SIZE | ID | OD | WP | BP | LENGTH | WEIGHT | MEASUREMENTS |
INCH | MM | MM | BAR | BAR | M | KG | MMXMMXMM | |
SZSPRHS-6.5 | 1/4 | 6.5 | 12 | 60 | 180 | 100 | 9 | 380X185X135 |
SZSPRHS-8.5 | 5/16 | 8.5 | 14 | 60 | 180 | 100 | 12 | 430X185X140 |
SZSPRHS-10 | 3/8 | 10 | 16 | 50 | 150 | 50 | 8 | 420X185X130 |
SZSPRHS-13 | 1/2 | 13 | 19 | 40 | 120 | 50 | 12 | 470X185X170 |
